TAILONZ PNEUMATIC 1/4"NPT 5 Way 2 Postion Air Hand Lever Operated Valve Pneumatic Solenoid Valve Manual Control Push-Pull 4H210-08
Amаzоn Crаzу 🔥 Dеаlѕ TAILONZ PNEUMATIC 1/4NPT 5 Way 2 Postion Air Hand Lever Operated Valve Pneumatic Solenoid Valve Manual Control Push-Pull 4H210-08 Simple review
So you can check out the other reviews at Amazon.com
only with $ 17.99
| Material | Aluminum |
| Brand | TAILONZ PNEUMATIC |
| Inlet Connection Type | National Pipe Tapered |
| Outlet Connection Size | 0.25 Inches |
- 【Product Name】 5 Way 2 Position Hand Pull Valve
- 【Size】1/4"NPT 【Working Medium】Air
- 【Working Pressure Range】25Psi~116Psi
- 【Product Features】Controls Air Flow On or Off
- 【Fittings】We provide matching fittings,You can connect directly to your 1/4 "or 6mm tube
Product Description
Product Features:
- Only 25psi Can Start the Solenoid Valve, Which is Easy to Operate, Easy to Install and Easy to Remove.
- The Valve Body is Made of High Precision Aluminum with High Hardness and Long Service Life.
- Air Inlet Port with 0.04mm Filter Screen, Can Filter Most Impurities and Dust, Keep the Valve Body Clean, Prolong Service Life
- Each Thread is Finely Processed, No Burrs, Smooth and Easy to Install.
- The Valve Body Contains a High Concentricity Seal Ring, Which is Not Easy to Leak, and the Rubber Pad with Lubricating Oil Reduces Friction.
- Each Product Comes with Fittings That Can Be Used Directly. No Need to Buy Additional Accessories, Just Insert 6mm or 1/4"tube.
- The Inner Hole is Processed by Special Process, with Small Friction Resistance and Long Service Life.
- Driven Automatically by Compressed Air. with Hand Lever, Can Be Controlled Manually to Deal with Some Special Situations.
- Widely Used to Control the Flow of Various Types of Fluids Such As Air, Water, Mud, Liquid Metals, Etc.
- The Five-port Two-position Manual Reset Type Manual Valve Adopts Spring Steel Ball Positioning, Which is Responsive and Easy to Switch. Please Pay Attention to Excessive Force and Control Position Error Caused by Mistake.
The Story Of Tailonz Pneumatic
Tailonz Pneumatic Professional Production of Pneumatic Parts, Air Filters, Solenoid Valves, Pneumatic Pipelines and Other Pneumatic Components.
We Develop Tools and Products for Ourselves and Our Customers Based on Actual Needs and Expectations.
All Products Are Directly Produced from the Factory to the Warehouse, We Ensure That Every Link, Every Process.
2 Position 5 Way Pneumatic Hand Pull Valve 4H210-08
Product Parameter
- Product Name:5 Way 2 Position Hand Pull Valve 4H210-08
- Type: Manual
- Working Medium:Air
- Port Size: Air Inlet (P)=1/4"NPT,Air Outlet(A B)=1/4"NPT,Air Exhaust(R S)=1/8"NPT
- Working Pressure Range:30Psi~116Psi
- Working Temperature:0~140℉ | 0~60°C
- Position and Port Number: 5 Port 2 Position
- Product Features:Controls Air Flow On or Off
- 1 × 4H210-08（Hand Lever Operated Solenoid Valve）
- 1 × Teflon Tape
- 3 × PC6-02
- 2 × Pneumatic Muffler SL-01
PRODUCT FEATURE
 |
 |
 |
|---|---|---|
High Quality SealUse High-quality Self-lubricating Sealant. Reduce Friction, Improve Sealing Performance, High and Low Temperature Resistance. | Pure Aluminum BodyThe Valve Body is Made of Pure Aluminum and Wire Drawing. Strong Pressure Resistance, Surface Oxidation Treatment, No Burrs on the Thread, and Long Service Life. | High Efficiency FiltrationThe Air Inlet is Equipped with a 40-micron Filter As Standard, Which Effectively Filters Impurities in the Air, Protects the Inner Wall and Prolongs the Service Life. |
- Notes:
- It is Recommended to Install an Air Filter to Ensure Clean Air into the Handplate Valve.
- Please Check Whether the Products and Accessories Are Damaged or Lost Before Using Them.
- Pay Attention to Whether the Air Flow Direction is Correct During Installation (as Shown in Page A+). Incorrect Air Flow Direction Will Cause the Solenoid Valve to Be Unable to Be Used Normally.
- Please Pay Attention to Whether the Service Environment Meets the Requirements of the Product (such As Air Pressure Range, Temperature Range, Voltage, Etc.).
- Please Do Not Use the Product in the Environment of Shaking or Vibration, Please Pay Attention to the Response of the Pneumatic Valve at Low Temperature.
- Before Installation, Please Check the Threaded Mouth for Impurities. After Cleaning, Wrap the Teflon Tape Around the Fittings for 3-5 Rings. Teflon Tape Should Not Block the Air Mouth Under the Fittings.
Product Working Status
- Working Condition:Manually Open the Valve,Air Cylinder Sticks Out.
- Closed State:Manually Close the Valve,Air Cylinder Retraction.
Packing Display Drawing
 |  |  |  |  |  | |
|---|---|---|---|---|---|---|
| 6mm PU TUBE | 4R210-08 | HV-02 | PB-08 | FV320 | FV420 | |
| Size | 6MM OD | 1/4''NPT | 1/4''NPT | 1/4''NPT | 1/4''NPT | 1/4''NPT |
| Style | 5 Way 2 Postion | 4 Way 3 Postion | 5 Way 2 Postion | 3 Way 2 Postion | 4 Way 2 Postion | |
| Material | Polyurethane | Aluminum And Plastic | Aluminum And Plastic | Aluminum And Plastic | Aluminum And Plastic | Aluminum And Plastic |
| Lowest Temperature | -4℉ | 0℉ | 0℉ | 0℉ | 0℉ | 0℉ |
| Maximum Temperature | 176℉ | 140℉ | 140℉ | 140℉ | 140℉ | 140℉ |
| Working Pressure | 0Psi~145PSI | 25-116PSI | 25-116PSI | 25-116PSI | 25-116PSI | 25-116PSI |
| Maximum Pressure | 145PSI | 116Psi | 116Psi | 116Psi | 116Psi | 116Psi |
Product Specifications
Specification for this product family
